Processing Equirectangular Images with Python

equilib

equilib is a library for processing equirectangular (360°) images in Python.

  • Pure Python, with numpy and torch as the only runtime dependencies.
  • Runs on CPU and CUDA tensors, with batched and mixed-precision processing.
  • Automatic input-type detection (numpy.ndarray or torch.Tensor).
  • Extras such as rotation-matrix creation and a customizable grid sampler.
  • Highly modular and extensible.

Quick start

pip install pyequilib

See Installation for development setup, then Usage for examples.

Transforms

equilib provides transforms between equirectangular, cubemap, and perspective images. Each transform ships both a class API and a func API.

Transform Description
Cube2Equi / cube2equi cubemap → equirectangular
Equi2Cube / equi2cube equirectangular → cubemap
Equi2Equi / equi2equi equirectangular → equirectangular
Equi2Pers / equi2pers equirectangular → perspective
Pers2Equi / pers2equi perspective → equirectangular

See the API Reference for the full signatures.

Citation

If you found this module helpful to your project, please cite this repository:

@software{pyequilib2021github,
  author = {Haruya Ishikawa},
  title = {PyEquilib: Processing Equirectangular Images with Python},
  url = {https://github.com/haruishi43/equilib},
  version = {0.6.0},
  year = {2021},
}

Acknowledgements
